Main Applications:
In the field of new energy vehicles, the equipment distributes power to slow charging, fast charging, defrosting, air conditioning, PTC and other systems to ensure the normal operation of each system. /DC function supplies power to low-voltage equipment such as interior lighting and control systems; /AC function supplies energy to AC loads such as air conditioners and compressors; The emergency power function provides critical power support in special situations, improving the safety and reliability of the vehicle.
Parameter Table
| The name of the project | Main parameters: |
| Operating voltage range | 350V~750V |
| Low voltage auxiliary supply voltage | 18V~32V |
| Dimensions | 544.5mm×330mm×190.5mm |
| Rated work efficiency | ≥98% |
| Cooling method | Water |
| Ingress protection | IP68 |
| DC/DC peak power | 3.6 kW |
| DC/AC peak power | 7.5 kW |
| Peak power of the emergency power supply | 5 kW |
| power distribution | Slow charging, fast charging, defrosting, air conditioning, PTC, etc |
