Main Applications:
In the new energy vehicle industry, water-cooled 2-in-1 equipment plays a vital role. It undertakes the task of high-voltage power distribution, distributes high-voltage power for key systems such as slow charging, fast charging, defrosting, air conditioning, and PTC of vehicles, and ensures the orderly operation of these systems. At the same time, its DC/DC conversion function can convert high-voltage direct current into low-voltage direct current, providing stable power supply for low-voltage electrical systems such as lighting and sensors in the vehicle. With excellent heat dissipation and protection performance, it can ensure the reliable operation of the vehicle's electrical system under various complex working conditions, improving the use experience and safety of the whole vehicle.
Parameter Table:
The name of the project | Main parameters: |
Operating voltage range | 250V~750V |
Low voltage auxiliary supply voltage | 9V~36V |
Dimensions | 544.5mm×330mm×190.5mm |
Rated work efficiency | ≥98% |
Cooling method | Water |
Ingress protection | IP68 |
DC/DC power rating | 1.5 kW |
High-voltage power distribution | Slow Charge, Fast Charge, Defrost , Air Conditioner, PTC, etc |
Product features | Contactor adhesion detection |
