Main Applications:
In the field of new energy vehicles, it supplies power to multiple systems of the vehicle. /DC function can convert high-voltage direct current to low-voltage direct current to supply power to low-voltage equipment such as interior lighting and control systems. /AC function converts direct current into alternating current to provide energy for AC loads such as air conditioning compressors, drive motors, and more. In addition, in some scenarios such as industrial equipment and communication base stations that require integrated power management, the power supply can also realize the reasonable allocation and conversion of power supply, ensure the normal operation of the equipment, and improve the overall performance and reliability of the system.
Parameter Table
| The name of the project | Main parameters: |
| Operating voltage range | 350V~750V |
| Low voltage auxiliary supply voltage | 24V |
| Dimensions | 390mm×294mm×185mm |
| Rated work efficiency | ≥98% |
| Cooling method | Water |
| Ingress protection | IP68 |
| DC/DC peak power | 3kW/6.6 kW |
| DC/AC peak power | 7.5kW/ 12 kW |
Main Applications:
In the field of new energy vehicles, it supplies power to multiple systems of the vehicle. /DC function can convert high-voltage direct current to low-voltage direct current to supply power to low-voltage equipment such as interior lighting and control systems. /AC function converts direct current into alternating current to provide energy for AC loads such as air conditioning compressors, drive motors, and more. In addition, in some scenarios such as industrial equipment and communication base stations that require integrated power management, the power supply can also realize the reasonable allocation and conversion of power supply, ensure the normal operation of the equipment, and improve the overall performance and reliability of the system.
Parameter Table
| The name of the project | Main parameters: |
| Operating voltage range | 350V~750V |
| Low voltage auxiliary supply voltage | 24V |
| Dimensions | 390mm×294mm×185mm |
| Rated work efficiency | ≥98% |
| Cooling method | Water |
| Ingress protection | IP68 |
| DC/DC peak power | 3kW/6.6 kW |
| DC/AC peak power | 7.5kW/ 12 kW |
