Key features:
Fast inflation: The volumetric flow rate and rated power of different models enable them to achieve rapid inflation and reduce waiting time for all kinds of tires, air cushions and other inflation equipment.
Stable pressure control: It can be accurately controlled at the rated pressure of 1.0MPa and the maximum allowable pressure is 1.2MPa, which can meet the requirements of a variety of items for inflation pressure and ensure the safety and effect of inflation.
Adaptable to harsh environments: IP67 waterproof rating and a wide operating temperature range of -40°C to 75°C ensure proper operation in wet and extreme temperature conditions.
Low noise and energy saving: The first-class energy efficiency level realizes energy saving and consumption reduction, and the noise level of 75dB ensures low noise during operation and does not interfere with the surrounding environment.
Parameter Table
| project | 1.8 - B | 1.8 - FB | 3.0 - FB | 4.0 - FB | 5.0 - FB |
| Model | 1.8 - B | 1.8 - FB | 3.0 - FB | 4.0 - FB | 5.0 - FB |
| Motor type | synchronous | synchronous | synchronous | synchronous | synchronous |
| Rated power of drive motor(Kw) | 1.8 | 1.8 | 3.0 | 4.0 | 5.0 |
| Volumetric flow rate (L/min) | 160 | 160 | 280 | 400 | 500 |
| Rated current(A) | 4.2 | 4.2 | 6 | 6.8 | 7.5 |
| Rated Frequency (Hz) | 125 | 125 | 125 | 120 | 118.5 |
| Nose Weight(Kg) | 18.5 | 23 | 38 | 42 | 43.5 |
| Noise Level (dB) | 75 | 75 | 75 | 75 | 75 |
| Vibration (mm/s) | ≤45 | ≤45 | ≤45 | ≤18 | ≤18 |
| Energy efficiency rating | Level 1 energy efficiency | Level 1 energy efficiency | Level 1 energy efficiency | Level 1 energy efficiency | Level 1 energy efficiency |
| Rated Pressure(MPa) | 1.0 | 1.0 | 1.0 | 1.0 | 1.0 |
| Maximum allowable pressure (MPa) | 1.2 | 1.2 | 1.2 | 1.2 | 1.2 |
| Rated Voltage (V) | AC380 | AC380 | AC380 | AC380 | AC380 |
| Operating ambient temperature limit (°C). | -40 ~ 75 | -40 ~ 75 | -40 ~ 75 | -40 ~ 75 | -40 ~ 75 |
| Waterproof rating | IP67 | IP67 | IP67 | IP67 | IP67 |
| Exhaust temperature (°C). | 85 (start-stop temperature). | 85 (start-stop temperature). | 85 (start-stop temperature). | 85 (start-stop temperature). | 85 (start-stop temperature). |
| SIZE - Length (mm) | 350 | 420 | 458 | 500 | 500 |
| SIZE - Width(mm) | 220 | 270 | 375 | 380 | 380 |
| SIZE - Height(mm) | 275 | 280 | 325 | 330 | 330 |
