DC/DC is a power conversion device that can convert DC voltage. It plays a key role in several areas:
New energy vehicles: Suitable for a variety of models, such as SUVs, mining trucks, etc., it can convert the battery input voltage into the stable voltage required by various systems of the vehicle to ensure the normal operation of the power system and auxiliary equipment.
Ship: Provide stable voltage for the ship's power system to meet the power demand of various electrical equipment on board.
Automotive air conditioner: Accurately adjust the voltage to ensure the efficient and stable operation of the automotive air conditioning system.
Photovoltaic power generation: Optimize the output voltage of photovoltaic cells, improve the efficiency and stability of power conversion, and facilitate power storage and grid connection.
Intelligent manufacturing: Provide stable and reliable power supply for automated production equipment and precision instruments to ensure production accuracy and normal operation of equipment.
5G communication: Stable power supply for base stations and other communication equipment to ensure the normal operation of signal transmission, data processing and other functions.
Parameter Table
| The name of the project | FH1K8 - 540DCDC1 - M01 | FH2k - 540DCDC1 - M01 | FH3k - 540DCDC1 - M01 | FH1k8 - 380DCDC1 - M01 | F3k3 - 540DCDC2 - M01 | FH4k - 540DCDC2 - M01 | FH6k6 - 540DCDC2 - M01 | FH9k - 540DCDC27 - W01 | FH15k - 540DCDC27 - W01 | FH800 - 540DCDC27 - W01 | FH1K2 - 540DCDC27 - W01 |
| Dimensions/mm | 20012045 | 20012045 | 20012045 | 20012045 | 20012045 | 26020057 | 26020057 | 370307172 | 608×382×283 | 249.514275 | 26917286 |
| Weight / kg | 1.2 | 1.2 | 1.2 | 1.2 | 1.2 | 4.3 | 4.3 | 10 | 30 | 3 | 3.5 |
| Input voltage/V (DC). | 200 - 750 | 200 - 750 | 200 - 750 | 200 - 430 | 400 - 720 | 200 - 750 | 200 - 750 | 350 - 750 | 350 - 750 | 350 - 750 | 350 - 750 |
| Output voltage/V (DC). | 14±0.2 | 14±0.2 | 14±0.2 | 14±0.2 | 27.5 ±0.5 | 27.5 ±0.3 | 27.5 ±0.3 | 27.5 ±0.3 | 27.5 ±0.3 | 27.5 ±0.3 | 27.5 ±0.3 |
| Rated power/kW | 1.5 | 1.8 | 2.4 | 1.5 | 3 | 4 | 6 | 9 | 15 | 0.8 | 1.2 |
| Peak power/kW | 1.8 | 2 | 3 | 1.8 | 3.3 | 4.8 | 6.6 | 10 | 16.5 | 0.84 | 1.4 |
| Applicable models | 8m≤ | 8m≤ | 8m≤ | 8m≤ | 6m - 12m | Fuel cell SUV | 6m - 12m | Fuel cell mining trucks | 200t mining truck | Chillers | Chillers |
